2

Warp beam flange

diameter(mm)

800-1000mm (Basic form)

(it can be customized according to customer requirements)

3

Beaming speed

(m/min)

100-800m/min stepless adjustable

4

Braking length

≤3 (500m/min)

5

Error of winding density

≤ 0.25%

6

Motor Power

11 KW

7

Bobbin cradle

Heading640,240×240mm(standard model)

(it can be customized)

8

Weight of main unit

3000 kg

9

Weight of bobbin

2800kg

10

Warping count deviation

≤0.05%

11

Reed traverse speed & scope

0～2.5mm/r(beam) & 0～20mm
