Application

Card the processed even batt completely and output even webbing and then feed to the next process.

Technica Data

Machine width : 1550mm 1850mm 2000mm 2300mm 2500mm

Output speed : s45m/min

Power : 21.5kw~28kw

Mechanical characters

Feeding is equipped with metal proof device, stainless steel under screen and pneumatic lfting safetyshield.Working roller and stripping roller adopt double row bearing structure. Shaftsleeve links shaft nose and bearing to keep shaft nose from wearing Patented suction device recydle the flying fiber to dust bag to keep clean.
